| CPU: |
Intel Core 2 Duo Processor 667/800Mhz, Santa Rosa
Speed - 1.6/1.8/2.0/2.2/2.4 GHz
Intel Celeron Processor 533Mhz |
| SYSTEM BIOS: |
Brand - Phoenix
Size of EEPROM - 1M
BIOS Architecture - EFI
|
| CHIPSET: |
North Bridge - Intel PM965
South Bridge - ICH8-M
Signal channel support
|
| MEMORY: |
DDRII SO-DIMM
256MB/512MB/1G/2G/4G
Number of Pins - 200
Speed - 533/677/800 MHz
Number of Slot - 2
Form Factor - 1.25 inch height
|
| VIDEO CONTROLLER: |
Intel 965 SMA 256M / Nvidia Geforce Go 8600 GS 512M GDDR2 PCIe,
|
| OPTICAL DISK DRIVE: |
Interface - IDE
Height - 12.7mm
Type - DVD Combo/Dual/ Super Multi
Bezel Type - GBAS
Others - CBB Compliant
|
| HARD DISK DRIVE: |
Interface - SATA
Height & Diameter - 9.5mm & 2.5"
RPM - 4200/5400/7200
Capacity - 40/60/80/100G/120/160/200 GB
Others - CBB Compliant
|
| DISPLAY: |
Size - 15.4"W
Type - TFT WXGA Crystal Bright Screen / WSXGA Anti-Glare Sreeen
Resolution - WXGA 1280x800 / WSXGA 1680x1050
Others - CBB Compliant
|
| KEYBOARD: |
Height - 6.5mm
Pitch - 19mm
Stroke - 3 mm
Width - 307mm
Layout - JP/US/EU
|
| POINTING DEVICE: |
Type - Glide touchpad without scroll bar
Number of Button - 2
|
| PC CARD SLOT: |
Type - New Card Type II 54mm
Interface - PCIE/USB
Number of Slot - 1
|
| AUDIO SYSTEM: |
Interface - Azalia
Output Channels - 5.1 analog output
Speaker - Two 1W stereo speaker
Subwoofer - 1.5 W
Volume Control - keyboard function key
Microphone - x1
|
| MEMORY CARD READER: |
Ejection Type - Non-push
Type of Card Support - SD/MS/MS Pro/MMC
|
| I/O PORT: |
USB - 4 (USB 2.0)
RJ-11 - 1
RJ-45 - 1
Line Out - 1
S/PDIF - 1
Microphone - 1
DC Input - 1
VGA Port - 1
DVI- 1 (with Nvidia 8600 VGA only)
DVI to HDMI adaptor optional
Kensington Lock - 1
|
| QUICK KEY: |
Number of Quick Key - 1
Definition - ECO
|
| INDICATOR: |
Number of Indicator - 6
Definition - WLAN/power/battery charge/cap lock/num lock/HDD & ODD
|
| MODEM: |
Interface - Azalia
Type & Speed - 56Kbps(V.90) Fax Modem
Form Factor - MDC 1.5
Assembling Capability - CE/CB
|
| LAN: |
Interface - MII Bus
Speed - 10/100Mbps
|
| WIRELESS LAN: |
Interface - PCIE/USB
Form Factor - abg/agn
Type - Mini PCIE
|
| BATTERY: |
Type - Li-Ion Cylinder
Number of Cell- 6 cell / 9 cell
Pack Capacity - 4400mAH/11.1V (6 cell), 6600mAH/11.1V (9 cell)
Assembling Capability - user Swappable
|
| AC Adapter: |
Type - Universal AC adaptor
Wattage - 90W
Input Voltage - 100V ~ 240V
Output Voltage - 19V
number of Pin - 2
D/C jack Dimension - 2.5mm*5.5MM*12.5mm
Others - CBB Compliant
|
| DIMENSIONS & WEIGHT: |
L x W x D mm - 359 x 255 mm x 25~36 mm
Kg - 2.9KG
|
| MICROSOFT LOGO: |
Windows Logo - Vista Premium
|
| REGULATION: |
EMC - CE
Safety - CB
|
| GREEN PRODUCT COVERAGE: |
ROHS - 6 European Union ROHS banned materials
Others - 12 universal GP product banned materials
|
| WEB CAM |
Build in 1.3M Web Cam Optional |
| Intel Trubo Memory: |
Minicard, Mini PCIE interface (1G, optional) |
