| CPU |
Intel Atom N270 1.6G Processor, 533 MHz FSB,512KB L2 Cache |
| Intel Chipsets |
Core Logic:945GSE+ICH7-M
VGA:GSE 945 Integrated
Audio:High Definition Audio
|
| Memory |
2GB Maximum, 1*SODIMM Slot,Double channel,DDR2 667 |
| Battery Bay |
Re-chargeable Lithium Ion Battery Pack(Prismatic Cell)
2S2P-----32.56W(at least 3 hr)
|
| HDD |
2.5” SATA HD |
| VGA Controller |
945GSE(Simultaneous and multi-monitor) |
| LCD Display |
10.2” XGA TFT(1024*600)
Brightness:200nits(typ)
Touch Screen, Multil touch optional |
| Camera |
1.3M USB Camera Built in |
| Audio |
Built in Stereo Speaker*2(High Quality)
Internal Stereo Microphone(Digital Mic)
|
| Communication |
Wireless 3945 B/G Network Connection(Mini-PCle)
10/100 Fast-Ethernet(RJ45)
|
| Pointing Device |
Touch screen |
| External connectors |
1*DC-IN Jack
1*Headphone Jack(3.5mm)
1*Stereo Mic Jack
3*4-pin USB 2.0 Port
1*MMC/SD Card Slot
1*D-Sub 15 Monitor out
1*LAN RJ45
|
| Color |
WHITE / BLACK |
| Dimension |
245(L)x 190(W)x 28(H-min.) 33(H-max.) |
| Weight |
1.1kg |
| Protection |
Tough plastic and rubberized case, with Hard Disk, LCD Soft Mount kit |
| Vesa Mount |
Ready |
