| Processor |
• 3rd generation Intel® Core™ i7 Quad Core processor
• 3rd generation Intel® Core™ i7/i5 Duo Core processor
• 2nd generation Intel® Core™ i3/i5 Duo Core processor
|
| Core Logic |
• 3rd generation Intel® HM77 Chipset |
| Display |
• 15.6” (39.62cm) FHD (1920 x 1080) 16:9 crystal bright screen
|
| Memory |
• Dual channel DDR3
• Two 204pins SODIMM sockets, support DDR3 1333/1600MHz (Real operation frequency depends on processor)
• Expandable memory up to 16GB, depends on 4GB/8GB SODIMM module
• nVIDIA® Optimus Technology
• GPU switchable between iGPU and dGPU |
| Storage |
• (Factory option) One changeable 12.7mm(H) Super Multi/ Blu-ray Combo/ Blu-ray Writer ODD, SATA interface
• Two changeable 2.5” 9.5 mm (H) HDD, SATA interface |
| Video Controller |
• NVIDIA® next generation Graphics
• Nvidia® Optimus Technology
• GT650M (N13P-GT)+1GB DDR3
• GPU switchable between iGPU and dGPU |
| Keyboard and Pointing Device |
• Multi language full size isolated keyboard with numeric pad
• Built in touch pad with multi-gesture and scrolling function and palm proof
• Three instant buttons WLAN on/off, Mute, CCD on/off
• Independent GPU switch support UMA and Optimus mode |
| I/O ports |
• 1 x USB 2.0 port
• 3 x USB 3.0 ports
• 1 x eSATA port (USB3.0 combo)
• 1 x external VGA port
• 1 x HDMI 1.4a output port (with HDCP)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x S/PDIF output jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 9-in-1 Push-Push Card reader
- MMC / RSMMC
- SD /Mini-SD /SDHC /SDXC
- MS /MS Pro /MS Duo |
| Slot |
• Two Mini Card slots
- 1st for WLAN Combo Half size Mini Card with PCIe and USB interface
- (Factory option) 2nd for 3.75G Full size Mini Card with USB interface |
| Communication |
• Built-in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory option) Intel® Centrino® Full size Mini Card module
• (Factory option) 1.3M / 2.0M pixels video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 20V, 6.0A, 120W
• Removable 6 cells Smart Lithium-Ion battery pack, 48.84WH
• (Factory option) Removable 6 cells Smart Lithium-Ion battery pack, 62.16WH
• Battery life : 220 minutes (with UMA mode ,48.84WH battery) (TBC)
• Battery life : 260 minutes (with UMA mode ,62.16WH battery) (TBC) |
| Security |
• Kensington® Lock
• (Factory option) Finger print
|
| Audio and Others Design |
• IMR
• High Definition Audio
• S/PDIF digital output
• Built in microphone
• Built in two speakers
• THX TruStudio Pro
|
| OS Support |
• Windows® 7/8 |
| Certificate |
• Windows® 7 (64-bit) Logo
• HDMI Logo |
| Dimension |
• 374(W) X 250(D) X 16.3~39.4(H)mm (TBC) |
| Weight |
• 2.7kg, including ODD and 48.84WH battery (TBC) |
