| Processor |
Intel® Core™2 Duo processors Centrino 2 45nm |
| FSB |
1066 Mhz
|
| Chipset |
|
| North Bridge |
nVidia MCP79MH
|
| South Bridge |
nVidia MCP79MH
|
| Memory |
|
| Module Type |
DDRII SO-DIMM
|
| Module Size |
1G/2G/4G
|
| Speed |
667/800/1066 MHz
|
| Number of Slot |
2
|
| VIDEO CONTROLLER |
|
| Mode |
One Switch for Single VGA or SLI VGA, Choice of longer battery life or higher performance |
| Brand & Model |
nVidia Geforce Go 9100M G up to 512MB + 9600M GS 512 MB DDRIII, 128bit memory bus, Hybrid SLI. |
| Optical Disk Drive |
|
| Interface |
SATA
|
| Type |
Super Multi/ HD-DVD/BD
|
| Hard Disk Drive |
|
| Interface |
SATA x1
|
| Height & Diameter |
9.5mm & 2.5"
|
| Others |
CBB Compliant
|
| DISPLAY |
|
| Size |
18.4" Wide
|
| Type |
TFT,
Crystal Bright Screen |
| Resolution |
18.4" HD+ 1680 x 945 pixels resolution (16:9) Crystal Bright Screen |
| KEYBOARD |
|
| Height |
5.6mm
|
| Pitch |
18.45mm
|
| Stroke |
2.6mm
|
| Width |
339mm
|
| Layout |
US/UI
|
| POINTING DEVICE |
|
| Type |
Underplastic touchpad without scroll bar
|
| Number of Button |
2
|
| PC Card slot |
|
| Type |
New Card Type II 54mm
|
| Interface |
PCIE/USB
|
| Number of Slot |
1
|
| Audio System |
|
| Interface |
Azalia
|
| Output Channels |
5.1 analog output
|
| Speaker |
Two 1W stereo speaker
|
| Subwoofer |
2W
|
| Volume Control |
keyboard function key
|
| Microphone |
x 1
|
| Memory Card Reader |
|
| Ejection Type |
Non-push
|
| Type of Card Support |
SD/MS/MS Pro/MMC
|
| I/O Port |
|
| USB |
3 (USB 2.0)
|
| USB/e-SATA |
1
|
| RJ-45 |
1
|
| Line Out |
1
|
| S/PDIF |
1
|
| Microphone |
1 |
| DC Input |
1 |
| Analog VGA Port |
1 |
| HDMI |
1
|
| Kensington Lock |
1
|
| Quick Key |
|
| Number of Quick Key |
1 |
| Definition |
ECO
|
| Indicator |
|
| Number of Indicator |
7
|
| Definition |
WLAN/BT/power/battery charge/cap lock/num lock/HDD & ODD
|
| LAN |
|
| Speed |
10/100/1000 Mbps
|
| Wireless LAN |
|
| Interface |
PCIE/USB
|
| Form Factor |
Mini PCIE Full size
|
| Type |
A/G/N
|
| Bluetooth |
|
| Interface |
USB
|
| Version |
2.0(EDR)
|
| Battery |
|
| Type |
Li-Ion Cylinder
|
| Number of Cell |
9 cell
|
| Pack Capacity |
6600mAH/11.1V (9 cell)
|
| Assembling Capability |
user Swappable
|
| AC Adapter |
|
| Type |
Universal AC adaptor
|
| Wattage |
90W
|
| Input Voltage |
100V ~ 240V
|
| Output Voltage |
19V
|
| number of Pin |
3
|
| D/C jack Dimension |
2.5mm*5.5MM*11.5~12.5mm
|
| Dimensions |
W403 x D280 x H 25~35mm
|
| Weight |
3.5 KG
|
| Webcam |
USB 2.0 interface 1.3M
|
| Audio DJ |
Synaptics cap sense MMB
|
| Windows Logo |
Vista Premium
|
| Regulation |
|
| EMC |
CE
|
| Safety |
CB, C-Tick
|
| Green Product Coverage |
|
| ROHS |
6 European Union ROHS banned materials
|
Australia Japan China Taiwan Brazil
