DreamVision IP DVR System 8CH (Up to 64CH)

$1,499 RRP (Inc-GST)

Reviews & Awards

Product Information

Expandable from 8 to 64 Channels NVR
Support ACTi, A-MTK, Axis, D-Link, Panasonic, Planet, Vivotek and Other IP Cameras
Support IP PTZ Cameras and Video Servers
Support MJPEG, MPEG-4 and H.264 IP Camera Video Compression Formats
Support Remote Monitoring via 3G/GPRS/Wi-Fi Mobile Handsets (Window & Symbian)
Up to 24TB Complete Data Storage Solution
Powerful Network Capability to support 16 Remote Clients Connection Simultaneously
Complete Bug Free Integration
Complete IP Camera Functions Integration

Specifications

System
OS Embedded Linux
IP Camera Compression MJPEG, MPEG-4 and H.264 Compression (Depend on IP camera)
Video Format NTSC/PAL (Depend on IP camera)
Display & Recording
Display Support 1024*768 and above high resolution
Support 4:3 and 16:9 wide screen display
Screen Division (4:3): 1/4/6/8/9/10/13/16
Screen Division (16:9): 1/4/6/8/9/14/17
Sequencer: 1/4/16
HDD storage display
Display password protection
Digital Zoom Support
Recording Resolution Min. 320*240, 1280*1024 and above
Recording FPS Per Channel Max. 30 fps (NTSC) / 25 fps (PAL)@D1 ; 8ch and 16ch
15 fps@SXVGA (1280*1024) (Depend on IP camera)
Recording Mode Continuous/Non-Recording/Motion/Event-Recording
Watermark Support
IVS (Intelligent Video Surveillance)(*)(optional) Line crossing, Flow counting, Missing object,
Unattended object and PTZ auto tracking
Alarm
I & O Camera Relations 1-1, 1-many, many-1, many-many
Alarm Behavior Event to zoom/Event to recording/Pop up message/
Event to DO output
Alarm Notice by E-mail, FTP, SMS
Video Loss Detection Support
Camera Mask Detection Support
Scene Change Detection Support
Storage & Backup
HDD 2 bay SATA HDD
RAID External raid box
Backup USB / IDE burning device (CD-RW, DVD±RW)
USB storage (Pen drive,HDD)
Disk Recycle Schedule User self-defines with range from 1 to 365 days
HDD Smart Diagnosis Support
Remote
Networking PPPoE, PPP, DDNS, DHCP
Mobile Viewer Support remote monitoring via 3G/GPRS/Wi-Fi Networks (Window & Symbian)
Web Viewer Max, 16 simultaneous remote clients
Support remote monitoring, playback, setup, backup,
reboot and upgrade
Max. 16 Ch SYNC playback
Central Management System Connect to Max. 64 NVRs, NDVRs and DVRs with 4096 channels
Support remote monitoring, playback, setup, backup and E-MAP
Max. 16 Ch SYNC playback
Support multiple monitors display (Max. 16)
Control Center NVR, NDVR and DVR health check with Min. 1000 connections
Others
User Account 128 user accounts with password expiry notification
Multiple levels user autharity (Admin/Supervisor/User)
UI Languages Dutch, English, French, German, Japanese, Portuguese,
Spanish, Simplified and Traditional Chinese
Time Sync Support Time Server, FM and RTC time sync
Physical
Power 110/230V, 50~60Hz
Gross Weight 4KG
Dimension 208mm(W)*325mm(L)*189mm(H)
