| Processor |
Intel® CoreTM i5-6200U Processor, 2 Cores / 4 Threads
2.3GHz, Max Turbo Frequency 2.8GHz, Max TDP 15W |
| Chipset |
Integrated into CPU |
| Display |
Intel® HD Graphics 520
Microsoft® DirectX® 12, OpenGL4.4 and OpenCL 1.2
Support VGA, HDMI & DisplayPort |
| Memory |
Two SO-DIMM slot, up to 16GB of DDR3L 1600 MHz |
| Storage |
Support 2.5inch Serial ATA Type HDD |
| Audio |
Realtek® High Definition Audio
(5.1) Digital audio via DisplayPort 1.2 connector
1x Audio out &S/PDIF combo jack on the front panel
1x Mic in jack on the front pane |
| Ethernet |
1x RJ45 Intel I211 port
1x RJ45 Intel I219 Gigabit Ethernet, Wake-on-LAN |
| Wireless |
Option IEEE 802.11ac & Bluetooth module |
| IR |
Onboard IR module
An infrared sensor on the front panel
1x 3.5mm audio jack for extended infrared sensor
Not included Remote Control (optional) |
| Expansion Slots |
1x SIM Card slot
3x Mini-PCI Express® (Full-length for mSATA SSD; Full-length for PCIE/USB /3G; Half-length for PCIe) |
| Peripheral interfaces |
4x USB3.0 (1 x Type-C USB3.0 on the back panel)
2x USB2.0
6x COM Port (one on the back panel)
1x DC-IN jack (19V /12V ) |
| OS Support |
Windows® 7,8.1,10 & Linux |
| System BIOS |
AMI EFI 64 Mbit BIOS |
| Cooler |
Fanless Heatsink |
| Operating Temperature |
0°C to +35°C
32°F to 95°F |
| Accessories |
1x Quick Guide 1x Driver CD
1x AC Adaptor 1x AC Power Cord
4x Circular Foot-padding |
| Dimensions |
10.3in x 6.9in x 1.4in
260mm x 175mm x 35mm |
