PHYSICAL SPECIFICATIONS |
|
Board size |
3000 mm * 2256 mm |
Board diagonal |
148 inches |
Active writing area |
1432 mm * 1060 mm |
Active diagonal |
70 inches |
Thickness |
Min.: 25mm
Max.: 55 mm |
Aspect ratio |
4:3 |
Shipping (including 2 boxes) |
Dimension
Box 1: 1615*1255*165mm
Box 2: 1615*1255*165mm
Net weight
Box 1: 30.5 KG
Box 2: 37.6 KG
Gross weight
Box 1: 37.5 KG
Box 2: 44.6 KG |
TECHNICAL SPECIFICATIONS |
|
Technology |
Electromagnetic induction |
Operating system |
Windows 2000/XP/2003/Vista |
PC connection |
RS232-USB; wireless module |
Resolution |
8192×8192 |
Data transmission rate |
19200 Baud Rate |
USB power supply |
DC 5V, 100mA |
Power consumption |
<2 W |
STORAGE & OPERATING SPECIFICATIONS |
Storage
-25º to 70º
10% to 90% relative humidity (non-condensing)
Operation
-20º to +55º
30% to 80% relative humidity (non-condensing) |
SOFTWARE FEATURES |
• Display 4 different pages simultaneously.
• Switch the location of different pages easily.
• Allow any separate page to be viewed in full.
• Requires the use of only one projector. |
Working Mode |
Control Mode/Windows Mode/Annotation Mode/Fullscreen Mode; |
Writing & Drawing |
Normal pen, Transparent pen, Flat pen, Brush pen, Texture pen; pen's color and width can be customized; |
Eraser |
4 kinds of eraser are available; |
Handwriting Recognition |
Draft writing can be recognized into text automatically; |
Geometrics Recognition |
Draft drawing of geometrics can be recognized into standard shape; |
Object Operation |
Object can be copied, cut, pasted, cloned, dragged, enlarged, lessened, rotated etc.; |
Replay |
All writing & drawing on the board can be replayed at different speed; |
Screen Recorder |
All operations on the board can be saved as the "AVI" format Video; |
Network Function |
With a common server, many whiteboards in different locations can be connected together; contents reflected on the different boards will be uniform, and users can enjoy the on-line education and remote conference via this function; |
Resource |
Abundant teaching resources are embedded in the software; users can also insert resources as per their need in teaching; |
Others |
Print, Send Email, Export Image/ html/ resource, Hyperlink, Insert & Edit Text, Skin, Background, User Management, Shortcut, Color Spay, Beeline, Geometrics. |
FREQUENTLY USED TOOLS |
|
Screen Shade |
Cover contents on the board; drag in different direction; customized background |
Move Page |
Extend the page, and move vertically |
Magnifier |
Magnify image and content on the board clearly |
Searchlight |
Highlight information on the board; shape and transparency can be changed |
Camera |
Capture content on the board; 4 types are available; |
Soft keyboard |
Used in text input and document saving |
Calculator |
Standard & Scientific Calculator are available |
Digital Clock |
For time reminding; Transparency & Size can be change; system clock, timing and countdown |
Protractor |
Shape, unit, size, scale and transparency can be changed |
Ruler |
Unit and transparency can be changed; can be rotated to different directions |
Compass |
Two types of graphic: Arc & Sector |
ACCESSORIES |
|
Electronic pen |
Specially designed for model WB-9000A-148, with 1.5V AAA batteries; |
USB-RS232 cable |
10 m |
Wall-mount bracket |
Packing dimension: 1330*375*145 mm
Net weight: 27.8KG
Gross weight: 31.8KG |
